LENOVO THINKPAD E14 GEN5 Intel® Core™ i7-1355U, 8GB RAM DDR4 3200/512GB SSD M.2 2242/NVIDIA® GeForce MX550 2GB GDDR6 – 14INCH” WUXGA-DOS-Graphite Black- 21JK0020GP
Key Features
- Part No. : 21JK0020GP
- SKU No. : TNC-001806N
- Brand : Lenovo
- Screen Size : 14 -inch
- Processor Type : Intel
- Processor : Intel i7
- Graphics : 2GB
- Memory : 8GB
- SSD : 512GB
- Operating System : DOS
- Description
Description
| Part No. | 21JK0020GP |
| Brand | Lenovo |
| Processor |
Intel® Core™ i7-1355U, 10C (2P + 8E) / 12T, P-core 1.7 / 5.0GHz, E-core 1.2 / 3.7GHz, 12MB |
| Graphics |
NVIDIA® GeForce MX550 2GB GDDR6 |
| Chipset |
Intel® SoC Platform |
| Memory |
8GB Soldered DDR4-3200 |
| Memory Slots |
One memory soldered to systemboard, one DDR4 SO-DIMM slot, dual-channel capable |
| Max Memory |
Up to 40GB (8GB soldered + 32GB SO-DIMM) DDR4-3200 |
| Storage |
512GB SSD M.2 2242 PCIe® 4.0×4 NVMe® Opal 2.0 |
| Storage Support |
Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB each |
| Storage Slot |
Two M.2 slots • One M.2 2242 PCIe® 3.0 x4 slot • One M.2 2242 PCIe 4.0 x4 slot |
| Card Reader |
No card reader |
| Optical |
None |
| Audio Chip |
High Definition (HD) Audio, Synaptic® CX11880 codec |
| Speakers |
Stereo speakers, 2W x2, Dolby Atmos® |
| Camera |
FHD 1080p with Privacy Shutter |
| Microphone |
2x, Array |
| Battery |
Integrated 57Wh |
| Power Adapter |
65W USB-C® (3-pin) |
| Display |
14″ WUXGA (1920×1200) IPS 300nits Anti-glare, 45% NTSC |
| Touchscreen |
None |
| Keyboard |
Non-backlit, English (UK) |
| Case Color |
Graphite Black |
| Case Material |
Aluminium (Top), Aluminium (Bottom) |
| Pen |
Pen Not Supported |
| Dimensions (WxDxH) |
313 x 219.3 x 17.99 mm (12.32 x 8.63 x 0.71 inches) |
| Weight |
Starting at 1.43 kg (3.15 lbs) |
| Operating System |
None |
| Bundled Software |
None |
| Ethernet |
100/1000M (RJ-45) |
| WLAN + Bluetooth |
Wi-Fi® 6, 802.11ax 2×2 + BT5.1 |
| WWAN |
Non-WWAN |
| SIM Card |
None |
| NFC |
None |
| Standard Ports |
1x USB 2.0 |
| 1x USB 3.2 Gen 1 (Always On) | |
| 1x USB-C® 3.2 Gen 2 (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4) | |
| 1x Thunderbolt™ 4 / USB4® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4) | |
| 1x HDMI® 2.1, up to 4K/60Hz | |
| 1x Headphone / microphone combo jack (3.5mm) | |
| 1x Ethernet (RJ-45) | |
| Smart Card Reader |
None |
| Security Chip |
Firmware TPM 2.0 Enabled |
| Fingerprint Reader |
Touch Style, Integrated in Power Button |
| Physical Locks |
Kensington® Nano Security Slot™, 2.5 x 6 mm |
| Other Security |
Camera privacy shutter |
| System Management |
Non-vPro® |
| Base Warranty |
1-year, Courier or Carry-in |
| Included Upgrade |
None |
| Bundled Accessories |
Lenovo® 15.6″ Laptop Casual Toploader |
| Green Certifications |
ErP Lot 6/26 |
| FSC certified package | |
| RoHS compliant | |
| TCO Certified 9.0 | |
| Other Certifications |
TÜV Rheinland® Low Blue Light (Software Solution) |
| Mil-Spec Test |
MIL-STD-810H military test passed |
